XL-805DMX

XL-805DMX

XL-805DMX 1ch PowerSport Amplifier

  • IPX67 Water Resistant Sealed Design
  • Aluminum Die-Cast end caps with integrated connectors
  • 800 Watt High Efficiency Class D Design
  • 1-OHM Stable Mono Block Amplifier
  • International Rectifier® Chip Set
  • Ultra Low Current Draw
  • 4-Layer Copper Plated PCB
  • Conformal Coated PC Board
  • PWM MOSFET Power Supply
  • Digital Sound Optimization Circuitry
  • High Damping Control Circuit
  • High Current Voltage Ripple Rejection Circuitry
  • 3.5mm AUX Input
  • Remote Soft Delay Turn On/Off Circuit
  • Variable Low Pass Electronic Crossover
  • Variable 18dB Bass Boost EQ
  • Variable Gain Control
  • Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output.
  • Remote Gain Control Included



Specifications

  • Peak Power: 1600 watts
  • Subwoofer Frequency Range: 10 Hz – 300Hz
  • Power Supply: Unregulated PWM
  • Inputs: RCA (speaker level compatible)/3.5mm Mini Jack Input
  • Dimensions (in Inches): 10″ x 4.6″ x 1.8″
  • Depth: 10″
  • Channels (mono): 1
  • 4-ohm Power: 350 watts
  • 2-ohm Power: 500 watts
  • 1-ohm Mono Power: 800 watts
  • Selectable Subwoofer EQ: 0-18d B Gain @ 45Hz
  • Variable Subsonic Freq: YES
  • Equalization Boost/Cut: 0 – 18 dB
  • Height: 1.8″
  • Width: 4.6″
  • Subwoofer EQ Frequency: 45 Hz
  • Low-Pass Crossover Freq: 40 Hz – 300 Hz
  • Crossover Slope: 12 dB
  • Input Sensitivity: 0.25 V – 10.0 V
  • S/N Ratio: >85 dB
  • Total Harmonic Distortion: 0.04% at Rated Power
  • Strapped Output Power @ 2ohms: N/A
  • Output Power (14.4 V) @ 4 ohm: 350 watts
  • Output Power (14.4 V) @ 2 ohm: 500 watts
  • Output Power (14.4 V) @ 1 ohm: 800 watts
  • Frequency Response: 10 Hz – 300 Hz
