| Operating Voltage: |
9 – 16 |
| Test Voltage: |
14.4 |
| Input Channel(s): |
4 |
| Output Channel(s): |
4 |
| Continuous Wattage @4ohm: |
150 x 4 / 500 x 2 |
| Continuous Wattage @2ohm: |
250 x 4 |
| Max Current Draw (Amps): |
100 |
| RCA Input Voltage Sensitivity: |
10 – 0.4 |
| High-Level Input Voltage Sensitivity: |
10 – 0.4 |
| RCA Input S/N: |
> 85 |
| Damping Factor: |
> 70 |
| THD: |
< 0.1% |
| Frequency Response (Hz): |
10 – 20k |
| High Pass Filter: |
50 – 5k |
| Low-Pass Filter: |
50 – 5k |
| Power Wire Gauge: |
8 |
| Speaker Wire Gauge: |
16 |
| Dimensions (Inches): |
7 x 4.5 x 2 |
| Dimensions (MM): |
|
