Description

IPX5 rated
Removable power terminal
Sealed removable signal connectors
Sealed top mount controls
Extruded aluminum heat sink
Signal sensing auto turn on
12dB/octave butterworth crossovers
Input select switch
LED light strip
Protection circuitry against:
Overload, short circuit, thermal & reverse polarity
Variable bass boost (0-12dB) centered at 45Hz
24dB Infrasonic Filter
Fully Variable crossover
Removable power terminal
Sealed removable signal connectors
Sealed top mount controls
Extruded aluminum heat sink
Signal sensing auto turn on
12dB/octave butterworth crossovers
Input select switch
LED light strip
Protection circuitry against:
Overload, short circuit, thermal & reverse polarity
Variable bass boost (0-12dB) centered at 45Hz
24dB Infrasonic Filter
Fully Variable crossover
| MM500.4V | |
| RMS POWER 4Ω | 80 x 4 |
| RMS POWER 2Ω | 125 x 4 |
| RMS POWER 1Ω | – |
| BRIDGED/MONO POWER 4Ω | 250 x 2 |
| THD% 4Ω | <1% |
| FREQ RESPONSE | 10Hz – 25kHz |
| DIMENSIONS L xW x H | 10.5 x 7.3 x 2 |
| INPUT RANGE | 200 mV – 20 V |
| AMP KIT | 8GKIT |
