Description
- Transducers
- 4x 2.75”(70mm) woofers, 2x 1”(25mm) tweeters, 2x 7.2”(182.8mm) x3”(76.2mm) Racetrack Passive Radiators
- Output Power
- 150WRMS, 300W PEAK (IEC60268)
- THD at Rated RMS Power
- < 1%
- Voltage Range
- 9.6 – 16VDC
- Quiescent Current Draw
- < 0.9A
- Maximum Current Draw
- 25A
- Frequency response
- 45Hz-40kHz
- Signal-to-noise Ratio
- > 80 dB
- Cable type
- 12AWG
- Cable length
- 12 Feet (3.66m)
- Bluetooth® Version
- 5.3
- Bluetooth® profile
- A2DP V1.3, AVRCP V1.6
- Bluetooth® transmitter frequency range
- 2400 MHz – 2483.5 MHz
- Bluetooth® transmitter power
- ≤ 15 dBm (EIRP)
- Aux-In
- 2Vrms(0.35Vrms – 2Vrms), 4Vrms(0.7Vrms – 4Vrms), 6Vrms(1.05Vrms – 6Vrms) (3.5 mm connector)
- Aux-Out
- 2 Vrms (3.5 mm connector)
- USB format
- FAT16, FAT32
- Soundbar Dimension (L x W x H)
- 21-5/32″ x 5″ x 4-5/8″ (537.5 x 126.7 x 118mm)
- Soundbar Weight
- 11.46 lbs (5.2kg)
- Packaging dimensions (W x H x D)
- 24″ x 9″ x 7.6″ (611 x 229 x 193mm)
- Gross weight
- 17 lbs (7.74 kg)
- 1x Soundbar
- 2x Security cables
- 1xSmall Wrench
- 1 x L- Small Allen wrench
- 1xT-handle hex wrench
- 2x Straps with Velcro
- 1X G -Clamp
- 1x Keychain
- 1x 12ft (3.66m) power/ground wire harness
- 2x Rubber top covers
- 2x Mount cleats
- 2x Short M8 screws
- 2x Short M5 screws
- 2x Long M5 screws
- 2x M5 screw nuts
- 4X Flat washers
- 2X C -Clamps (2″ )
- 2X C -Clamps (1.75″ )
- 2X Thick rubber strips (for 1.5″ pole )
- 2x Thin rubber strips (for 2″ &1.75″ pole)
- 1x Quick start guide
- 1x Safety sheet &warranty card
