The MRX1 is DS18’s NEW all in one marine head unit that does it all!
- V4.2 Bluetooth pairing functions so you can play music direct from your phone or any BT source.
- It comes precise sound settings options that let’s you control the bass, treble, balance, fade, EQ, loudness, and Subwoofer crossover with ease.
- We have Included preset EQ options that give you a better sound for your selected music preference that include FLAT, POP, ROCK, CLASSICAL, and EQ can be turned off all together.
- There is an easy to read LCD display with RGB keys so you can use the color that’s easiest to read, to set your mood of the day, or color scheme!
- Also provided is CT sync that allows for settings like time be adjusted by over the air radio frequencies.
- The USB can transfer music along with charging your chosen device at the rate of 2a.
- The MRX1’s sound output cant be matched because we have made this unit to use 4v pre amp outputs so you can expect the highest quality sound with the voltage to push it.
- The MRX1 has 3 outputs to accommodate fully applied systems easily with front, rear, and sub high quality outputs.
- -The IP65 waterproof rating will help you stay confident while using the headunit in harsh and wet terrain without failure.
- This radio has an amazing power output. With a 4 ohm load you will get 4×15 watts rms and 2 ohm load you will get 4×20 watts rms which is enough to push most entry level speakers. (Amps will be required to install tower speakers and subs)
- Enjoy all your favorite AM/FM stations with our wideband AM/FM receiver that is also selectable under source controls.
AM/FM Antenna |
Yes |
Audio Input(L+R) |
Yes |
USB For Music & Charging |
Yes, Charging 2A |
Wired Remote Input |
Yes |
Outputs- Rear Chassis |
|
Speaker Power Plug |
Yes,Molex Plug 12pin Water Resistant |
Audio Output Front (L+R) |
Yes |
Audio Output Rear (L+R) |
Yes |
Subwoofer Output RCA |
Yes |
Sub out low pass filter |
Yes, 80/120/160Hz, Gain 0-12 |
Media Playback |
|
USB (64G Memory) |
Yes |
Bluetooth v4.2 |
Yes |
BT Streaming ID3 Tag info |
Yes |
Other Features |
|
Operating Voltage |
12V |
Preamp Output |
4V RMS Differential |
LCD Display type |
Negative VA |
Backlight |
Yes |
IR Remote |
No |
Low Battery Beep |
Yes |
EEPROM |
Yes |
Conformal Coating |
Yes |
IPX Rating |
IPX 6 |
UV Resistance |
Yes |
Salt Spary Resistance |
Yes |
