SPECS

SKU
RZR-GBSUB10LD
Nominal Diameter
10″ / 254mm
Nominal Impedance
2 Ohms
RMS Power Handling
600W
MAX Power Handling
1200W
Sensitivity (1w/1m)
92dB
Frequency Response
25Hz-250Hz
Recommended Low Pass Crossover
120Hz

Body / Features

Enclosure Material
Polyethylene (PE)
Marine Grade Type
IP65
Sold in Pair or Single
Single
Color / Finish
Black
Port Plug Cover
Yes (Rubber)
Direct OEM Fit
Yes

Woofer Specifications

Voice Coil Diameter
2″ / 50.8mm
Voice Coil Former Material
Black Aluminum
Winding Material
SV
Cone Material
Non-Pressed Paper
Dust Cap Material
Carbon Fiber
Surround Material
Rubber
Basket Material
Steel
Magnet Material
Ferrite
Magnet Weight
81 Oz

Thiele & Small Parameters

Equivalent Volume VAS
23.67L / 0.835ft3
Excursion (one way) XMAX
21mm
Free Air Resonance FS
37Hz
Mechanical Factor QMS
5.07
Electrical Factor QES
0.76
Total Factor QTS
0.66
Moving Mass MMS
140.16g
Compliance CMS
0.13mm/N
Bl Factor BI
9.26
Voice Coil Inductance LE
0.38mH
Diaphragm Area SD
352.99cm2
DC Resistance RE
